Professional and Industrial Applications

Find the right lamp for your BARCO projector

BARCO

Please click on your projector model to find the right lamp.

8S

Product reference	Product number	Warranty	Service warranty (h)	Rated wattage (w)	Power Range [Watt]	Current Range [Amps]
XBO 1200W/DHP	69596	3000	3800	1200	840 - 1200	41 - 63
XBO 1600W/DHP	69840	3000	3800	1600	1120 - 1600	57 - 86
XBO 2200W/DHP	67484	1500	2000	2200	1540 - 2200	68 - 95

10S

Product reference	Product number	Warranty	Service warranty (h)	Rated wattage (w)	Power Range [Watt]	Current Range [Amps]
XBO 1200W/DHP	69596	3000	3800	1200	840 - 1200	41 - 63
XBO 1600W/DHP	69840	3000	3800	1600	1120 - 1600	57 - 86
XBO 2000W/DHP L	68884	3300	3500	2000	1400 - 2000	64 - 95
XBO 2200W/DHP	67484	1500	2000	2200	1540 - 2200	68 - 95

12C

Product reference	Product number	Warranty (h)	Service warranty (h)	Rated wattage (W)	Power Range (W)	Current Range (A)
XBO 1200W/DHP	69596	3000	3800	1200	840 - 1200	41 - 63
XBO 1600W/DHP	69840	3000	3800	1600	1120 - 1600	57 - 86
XBO 2000W/DHP L	68884	3300	3500	2000	1400 - 2000	64 - 95
XBO 2200W/DHP	67484	1500	2000	2200	1540 - 2200	68 - 95

15C

Product reference	Product number	Warranty (h)	Service warranty (h)	Rated wattage (W)	Power Range (W)	Current Range (A)
XBO 1200W/DHP	69596	3000	3800	1200	840 - 1200	41 - 63
XBO 1600W/DHP	69840	3000	3800	1600	1120 - 1600	57 - 86
XBO 2000W/DHP L	68884	3300	3500	2000	1400 - 2000	64 - 95
XBO 2200W/DHP	67484	1500	1800	2200	1540 - 2200	68 - 95
XBO 2500W/DHP	69089	1700	2000	2500	1700 - 2500	63 - 95
XBO 3000W/DHP	69480	1500	1900	3000	2100 - 3000	77 - 113
XBO 3000W/DHP L	69048	1900	2100	3000	2100 - 3000	76 - 111
XBO 3000W/DHP XL	59938	2200	2400	3000	2100 - 3000	77 - 113
XBO 4000W/DHP	69481	1100	1400	4000	2940 - 4200	91 - 130
XBO 4000W/DHP L	69049	1300	1500	4000	2940 - 4200	95 - 137
XBO 4000W/DHP XL	59940	1900	2100	4000	2940 - 4200	91 - 130

20C

Product reference	Product number	Warranty	Service warranty (h)	Rated wattage (w)	Power Range [Watt]	Current Range [Amps]
XBO 1200W/DHP	69596	3000	3500	1200	840 - 1200	41 - 63
XBO 1600W/DHP	69840	3000	3300	1600	1120 - 1600	55 - 85
XBO 2000W/DHP L	68884	3300	3500	2000	1400 - 2000	60 - 90
XBO 2200W/DHP	67484	1500	1800	2200	1540 - 2200	68 - 95
XBO 2500W/DHP	69089	1700	2000	2500	1700 - 2500	63 - 95
XBO 3000W/DHP	69480	1500	1900	3000	2100 - 3000	77 - 113
XBO 3000W/DHP L	69048	1700	2000	3000	2100 - 3000	76 - 111
XBO 3000W/DHP XL	59938	2200	2400	3000	2100 - 3000	77 - 113
XBO 4000W/DHP	69481	1100	1400	4000	2940 - 4200	91 - 130
XBO 4000W/DHP L	69049	1300	1500	4000	2940 - 4200	95 -137
XBO 4000W/DHP LL	59939	1500	1900	4000	2940 - 4200	91 - 130
XBO 4000W/DHP XL	59940	1900	2100	4000	2940 - 4200	91 - 130

19B

Product reference	Product number	Warranty	Service warranty (h)	Rated wattage (w)	Power Range [Watt]	Current Range [Amps]
XBO 1200W/DHP	69596	3000	3800	1200	840 - 1200	41 - 63
XBO 1600W/DHP	69840	3000	3800	1600	1120 - 1600	57 - 86
XBO 2000W/DHP L	68884	3300	3500	2000	1400 - 2000	64 - 95
XBO 2200W/DHP	67484	1500	2000	2200	1540 - 2200	68 - 95
XBO 2500W/DHP	69089	1700	2000	2500	1700 - 2500	63 - 95
XBO 3000W/DHP	69480	1500	1900	3000	2100 - 3000	77 - 113
XBO 3000W/DHP L	69048	1700	2100	3000	2100 - 3000	76 - 111
XBO 3000W/DHP XL	59938	2200	2400	3000	2100 - 3000	77 -112
XBO 4000W/DHP	69481	1100	1400	4000	2940 - 4200	91 - 130
XBO 4000W/DHP L	69049	1300	1500	4000	2940 - 4200	95 - 137
XBO 4000W/DHP LL	59940	1500	1900	4000	2940 - 4200	91 - 130
XBO 4000W/DHP XL	59940	1900	2100	4000	2940 - 4200	91 - 130

23B

Product reference	Product number	Warranty	Service warranty (h)	Rated wattage (w)	Power Range [Watt]	Current Range [Amps]
XBO 1200W/DHP	69596	3000	3800	1200	840 - 1200	41 - 63
XBO 1600W/DHP	69840	3000	3800	1600	1120 - 1600	57 - 86
XBO 2000W/DHP L	68884	3300	3500	2000	1400 - 2000	64 - 95
XBO 2200W/DHP	67484	1500	2000	2200	1540 - 2200	68 - 95
XBO 2500W/DHP	69089	1700	2000	2500	1700 - 2500	63 - 95
XBO 3000W/DHP	69480	1500	1900	3000	2100 - 3000	77 - 113
XBO 3000W/DHP L	69048	1900	2100	3000	2100 - 3000	76 - 111
XBO 3000W/DHP XL	59938	220	2400	300	2100 - 3000	77 - 113
XBO 4000W/DHP	69481	1100	1400	4000	2940 - 4200	91 - 130
XBO 4000W/DHP L	69049	1300	1500	4000	2940 - 4200	95 - 137
XBO 4000W/DHP LL	59939	1500	1900	4000	2940 - 4200	91 - 130
XBO 4000W/DHP XL	59940	1900	2100	4000	2940 - 4200	91 - 130

32B

Product reference	Product number	Warranty	Service warranty (h)	Rated wattage (w)	Power Range [Watt]	Current Range [Amps]
XBO 4500W/DHP	69463	1000	1300	4500	3150 - 4500	108 - 155
XBO 4500W/DHP L	69050	1300	1500	4500	3150 - 4500	108 - 155
XBO 6000W/DHP	69463	650	800	6000	4500 - 6000	140 - 175
XBO 6000W/DHP L	69053	800	1000	6000	4500 - 6000	140 - 175
XBO 6000W/DHP XL	59969	1000	1200	6000	4500 - 6000	140 - 175
XBO 6500W/DHP	4062172030731	500	750	6500	5000 - 6500	133 - 173
XBO 6500W/DHP L	54337	600	750	6500	5000 - 6500	133 - 173
XBO 6500W/DHP XL	55225	800	900	6500	5000 - 6500	133 - 173
XBO 6500W/DHP IX	4062172363792	1000	1200	6500		133 - 173
XBO 7000W/DHP	55226	400	500	7000	4900 - 7000	130 - 175
